Features:
1,Excellent mechanical strength, impact-resisting, and non-cracking bottle mouth and thread are of precise measurement, enabling 100% close match with the bottle cap.
2,The weight of the product can be preset with consistency.
3,The measurement and thickness of the product can meet the requirements of the design without any deviation. The surface of the bottle mouth and the body is of good luster and smoothness.
4,No rough selvedge will occur at the mouth or bottom of the bottles, which can save raw material.
5,There is no joint seam on the bottom of the bottle; And the strength is improved.
6,The joint seam on the bottle body is smooth.
7,Accord with GMP authentication requirements
| No. | item | Unit | Data |
| 1 | Dia.of screw | mm | 50 |
| 2 | Screw L/D | | 21 |
| 3 | Shot volume | cm³ | 325 |
| 4 | Injection Weight | g | 300 |
| 5 | Injection Pressure | Mpa | 167 |
| 6 | Max.screw stroke | mm | 210 |
| 7 | Max.screw speed | rpm | 10-235 |
| 8 | Heating capacity | kw | 8 |
| 9 | No.of heating zone | Qty | 3 |
| 10 | clamping&blowing system | | |
| 11 | clamping force of injection | KN | 500 |
| 12 | clamping force of blowing | KN | 150 |
| 13 | opening stroke of mold plant | mm | 120 |
| 14 | lifign height of rotary table | mm | 60 |
| 15 | max.platen size | mm | 580*390 |
| 16 | min.mold thickness | mm | 240 |
| 17 | heating capacity of mould | Kw | 2.5 |
| 18 | stripping system | | |
| 19 | stripping troke | mm | 210 |
| 20 | driving system | | |
| 21 | motor power | kw | 20 |
| 22 | hydraulic pressure | Mpa | 14 |
| 23 | product range | | |
| 24 | suitable bottle range | L | 0.015-0.8 |
| 25 | max.bottle height | mm | ≤200 |
| 26 | max.dia.of bottle | mm | ≤100 |
| 27 | other | | |
| 28 | dry cycle | s | 4 |
| 29 | min.Air pressure | Mpa | 1.2 |
| 30 | discharge rate of compressed air | m³/min | ＞0.8 |
| 31 | water flowage | m³/h | 3.5 |
| 32 | total rated power with mold heating | Kw | 30 |
| 33 | Dimension(L*W*H) | mm | 3800*1600*2230 |
| 34 | net weight | T | 7.5 |
