BST-1000A Injection molding machine
Shot weight is 128-162 g
Max opening stroke :320 mm
Space between the tie-bars : 385 X 350 mm
we have Imported advanced computer systems, Chinese / English interface
You can save 50 sets of mold parameters.
Advanced clamping structure and injection parts, precision hydraulic system and circuit design
Suitable for producing different types of precision small parts
|
Style:
|
|
|
Condition:
|
|
|
Automatic:
|
|
|
Payments:
|
|
|
Quantity:
|
|
- Shot Weight is128g
- Max Opening Stroke:320 mm
- Space Between Tie-bars:385X350 mm
- Imported advanced computer systems, Chinese / English interface
- Can save 50 sets of mold parameter
- Advanced clamping structure and injection parts, precision hydraulic system and circuit design
- Suitable for producing different types of precision small parts
- A variety of text can be switched
- Manual, semi-automatic and fully automatic mode
- Automatic movement monitoring with alarm and fault diagnosis
- Function of slope setting can set the start and stop of movements, so as ensure the smooth movement
| MODEL | BST-1000A | ||||||
| INJECTION UNIT | | A | B | ||||
| Screw diameter | mm | 36 | 38 | ||||
| Shot size(theoretical) | Cm³ | 143 | 180 | ||||
| Shot weight | g | 128 | 162 | ||||
| Injection pressure | Mpa | 183 | 164 | ||||
| Injection rate | g/s | 90 | 98 | ||||
| Screw L/D ratio | L/D | 21.6 | 20.5 | ||||
| Screw speed | r.p.m | 0-190 | |||||
| Nozzle Diameter | Srmm | 10 | |||||
| CLAMPING | | | |||||
| Clamp tonnage | KN | 1000 | |||||
| Toggle stroke | mm | 320 | |||||
| Mould Thickness | mm | 150-400 | |||||
| Space between tie-bars | mm | 385X350 | |||||
| Ejector stroke | mm | 125 | |||||
| Ejector tonnage | KN | 50 | |||||
| Ejector number | Piece | 5 | |||||
| Hole Diameter | mm | 100 | |||||
| OTHERS | | | |||||
| Heat power | KW | 7.6 | |||||
| Max. pump pressure | MPa | 16 | |||||
| Pump motor power | KW | 11 | |||||
| Valve Size | mm | 10 | |||||
| Machine dimension | m | 4.3X1.5X1.6 | |||||
| Machine weight | t | 3.4 | |||||
| Oil tank capacity | L | 180 | |||||
FEATURES
- A variety of text can be switched.
- Manual, semi-automatic and fully automatic mode.
- Automatic movement monitoring with alarm and fault diagnosis.
- Function of slope setting can set the start and stop of movements, so as ensure the smooth movement
CONTROL SYSTEM
All-digital control system uses dedicated controller, multiple CPU processing division,
a multi-functional automatic fault detection, alarm system, certificates 99 mold of
processing procedures, with remote control interface. System is of high stability and
responsiveness. System uses color LCD, man made interface for easy operation and
with a number of peripheral interfaces.
HYDRAULIC SYSTEM
Advanced hydraulic system design, through proportional control of pressure, flow achieves rapid multi-level pressure, speed switching, the system configuration is reasonable, stable and reliable. The noise is less than 75 dB. The medium and large machine adopts a two-way cartridge inserted valve system to improve the system of flow and speed of response, and makes the whole machine reach the best performance.
